Aluminum nitride (AlN) crucibles, due to their unique material properties, have extensive application value in high-temperature and special environments.
Provide extremely stable solutions for semiconductor, crystal growth and high-temperature experiments
Key Features
①Withstands Extreme Temperatures (Up to 2200°C) – Stable in inert atmospheres, far outperforming conventional ceramic crucibles
②Exceptional Thermal Conductivity (170 W/m·K) – Ensures uniform heating, minimizes thermal stress, and enhances crystal growth quality
③Zero Carbon Contamination – Graphite-free, preventing impurity doping in metal melting or semiconductor processing
④Superior Corrosion Resistance – Resists molten metals (Al/Cu/Ga) and aggressive salts
Item No :
Aluminum Nitride (ALN) CrucibleSize :
CustomizationProduct Origin :
CHINAColor :
Gray-whiteAluminum nitride crucibles are widely popular in many industries and fields.
Common Applications
Semiconductor Industry: GaAs/GaN single-crystal growth, electronic packaging materials
Materials Science: Melting high-melting-point metals (W/Mo), synthesizing nitrides/carbides
Energy Storage: High-temp sintering of lithium battery cathodes, solid-state electrolyte research
Industrial Use: Precision ceramic sintering, optical glass processing
Data Sheet
| Properties | Condition | Units | AN-180 |
| Density | -- |
g/cm3 |
3.32 |
| Thermal conductivity | 25℃ |
W/m·K |
180 |
| Bending strength | 3-point method,25℃ |
MPa |
410 |
| Insulation | 25℃ |
KV/mm |
31 |
| Volume resistity | 25℃ |
Ω·cm |
3.4×1014 |
| Dielectric constant | 1MHz |
— — |
8.8 |
| Dielectric loss | 1MHz |
— — |
6.5×10-4 |
| CTE | 25~400℃ |
×10-6/K |
4.6 |
Our advantage
Xiamen Juci Technology has a plant area of 30,000 square meters, and the production workshop is equipped with 30 sets of single sintering furnaces, as well as 8 sets of advanced continuous sintering furnaces, with a production capacity of up to 1,000 tons/year of aluminum nitride powder. The testing center is about 800 square meters, equipped with more than 100 sets of professional powder and ceramics testing equipments such as scanning electron microscope, particle size meter, nitrogen-oxygen analyzer, powder comprehensive tester, thermal conductivity meter and so on. The company has a R&D center with an area of 1200 square meters, equipped with more than 40 sets of R&D special equipment, and a R&D team of more than 30 people who constantly promote product optimization and innovation, so that the company can maintain its competitive advantage in the fierce market competition.
